OFP-15W33
15.6” Full-HD PCAP Multi-Touch Fanless Open Frame Panel PC with Intel® Celeron® J3455 Processor
Related Tags
The EPD-42T all-in-one solution can be utilized as a communications board, replacing a traditional white board. It takes advantage of projected capacitive touch (PCAP) technology to produce a vibrant, interactive display. PCAP consists of an insulator such as glass, which is coated with a transparent conductor. That distortion is measurable as a change in capacitance, resulting in crisp, easy-to-read displays. Because it doesn’t emit any light, the display is suited for hospital environments, as it doesn’t disturb patients with bright lights. And information displayed on the digital paper solution is “always on,” even if the power is removed.
ProductFeatures
- 15.6” Full-HD Open frame panel PC with PCAP Touch
- Onboard Intel® Celeron® J3455 SoC BGA Processor (2M Cache, up to 2.30 GHz)
- 2 x 204-pin DDR3L 1333 & 1600 MHz SO-DIMM support up to 16GB
- 2 x GbE LAN, 4 x USB 3.0, Line-out, Mix-in, 1 x COM, DP++, HDMI/DP
- Option for 4 x COM, 4 x USB 2.0, 16-bit GPIO with DB9 connector
- Slim & Strength Design
- Fanless Operation from 0°C ~ 45°C
- Wide Voltage Input +12V ~ 24V DC
- Option for Wi-Fi & BT function
- Option for Infineon SLB9665 TPM 2.0
ProductIntroduction
Panel Mounting demonstration (please refer to user manual for detailed SOP)
ProductSpecification
System Information
-
Processor
Onboard Intel® Celeron® J3455 SoC BGA Processor (2M Cache, up to 2.30 GHz)
-
System Memory
Default with 4GB DDR3L Memory
Option supports up to 16GB DDR3L 1600 & 1333MHz SO-DIMM -
I/O Chipset
EC iTE IT8528
-
BIOS Information
AMI 128Mbit SPI BIOS
-
Watch Timer
H/W Reset: 1 sec. ~ 65535 sec./min. and 1 sec. or 1 min./step
-
H/W Status Monitor
Monitoring System Temperature and Voltage with Auto Throttling Control
-
CPU Cooler (Type)
Fanless Heatsink
-
Board
EMX-APLP
Expansion
-
Expansion
1 x M.2 (2230) A-Key support Wi-Fi module
Storage
-
Storage
Default with 64GB mSATA
-
Other Storage Device
Reserve space for 1 x 2.5” Drive Bay design (by option)
Panel
-
Panel
example
I/O
-
I/O
example
DC in/out Characteristics
-
DC in/out Characteristics
example
Display
-
Display
example
Audio
-
Audio
example
Certifications
-
Certifications
example
Ethernet
-
Ethernet
example
Mechanical & Environmental
-
Mechanical & Environmental
example
Software Support
-
Software Support
example
Ordering Information
-
Ordering Information
example
Ordering Information
-
OFP-15W33-345-A2R
15.6” Full-HD Multi Touch Open Frame Panel PC / Intel Celeron J3455, 4GR,64GB
mSATA,4USB3,COM,2LAN,DP++,DP,HDMI without adapter -
OFT-15W33-3455-A1-1R(RS 2 inside)
15.6” Full-HD Multi Touch Open Frame Panel PC / Intel Celeron J3455, 4GR,128GB
SSD,4USB3,COM,2LAN,DP++,DP,HDMI without adapter, Windows 10 -
ACC-OFT-15-PMT-01R
Panel Mount Kits for OFT-15W series
-
ACC-OFT-15-WMT-01R
Wall Mount Kits for OFT-15W series
